High Safety 48v Long Life Cycle Battery 60ah 3 Years Warranty Stable Performance
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HB |
| Certification: | ROHS |
| Model Number: | 48V 60mAh |
| Minimum Order Quantity: | Contact sales to get |
| Price: | Contact sales to get |
| Packaging Details: | Contact sales to get |
| Delivery Time: | Contact sales to get |
| Payment Terms: | T/T |
| Supply Ability: | Contact sales to get |
| NominalVoltage: | 48V | NominalCapacity: | 60Ah |
|---|---|---|---|
| MinimumCapacity: | 55Ah | Warranty: | 3Yea |
| CycleLife: | ≥2000Times | 1 | 1 | BatterySize: | L:408W:275T:140(max) |
| HighLight: | fastcharginglithiumionbatteries,hybridvehiclebatterypacks |
Battery composition
| Serial number | name | model | Note |
| 1 | Lithium ion battery | 32650-5000mAh 3.2V | 15S12P |
| 2 | Battery protection board | JP15S60A | |
| 3 | Stainless steel case (including handle) | JP234170 | Charge display board |
| 3 | Charging terminal | Anderson SB-60A connector | |
| 4 | Discharge terminal | Anderson SB-60A connector |
Main technical parameters
| Serial number | project | Specification requirements | Note |
| 3 .1 | Typical capacity | 60 Ah | 0.2 C charge and discharge to termination voltage |
| 3 .1 | Minimum capacity | 54 Ah | |
| 3 .2 | Q | 51.2 V | |
| 3 .3 | Battery internal resistance | ≤ 300 m Ω | AC 1KHz test after standard charging |
| 3 .4 | Charging voltage | 5 4.75 ± 0.5 V | |
| 3 .5 | recharging current | ≤ 60.0 A | |
| 3 .6 | Maximum continuous discharge current | 120 A | |
| 3 .7 | Overcurrent protection current | 150 ~ 200 A | |
| 3.8 | Combination | 1 5 S 12 P | |
| 3 .9 | Discharge cut-off voltage | 37.5 ± 0.5 V | |
| 3 .10 | Operating temperature | 0 ~ + 45 ℃ | Charge |
| – 2 0 deg.] C ~ + 55 deg.] C | Discharge | ||
| 3 .11 | Storage temperature | – 2 0 deg.] C / + 45 deg.] C | Less than a month |
| – 2 0 deg.] C / + 35 deg.] C | Less than six months | ||
| – 2 0 deg.] C ~ + 2 . 5 deg.] C | Within a year | ||
| 3 . 12 | Electric battery weight | About: 26 ± 0.5k g | Estimate |
| 3.13 | Battery size | Max .: length 408 * width 275 * thickness 140 mm |
|
Green-Safe Energy’s pure electric, hybrid, and plug-in hybrid vehicle battery packs and solutions meet the requirements of long cycle life, excellent power and energy, fast charging and high safety performance that are currently being pursued by car manufacturers. At the same time, it also provides fixed energy storage power for large-scale power grid equipment, peak-to-valley regulation schemes, and consumer energy storage battery packs to help the development of green energy.
