18650 11.1 V Lithium Ion Battery Pack For Library Robot 0.2c Standard Discharge Current
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HB |
| Certification: | ROHS |
| Model Number: | |
| Minimum Order Quantity: | Contact sales to get |
| Price: | Contact sales to get |
| Packaging Details: | Contact sales to get |
| Delivery Time: | Contact sales to get |
| Payment Terms: | T/T |
| Supply Ability: | Contact sales to get |
| NominalVoltage: | 11.1V | NominalCapacity: | 35200 |
|---|---|---|---|
| Warranty: | 1Year | CycleLife: | 500Times |
| StandardDischargeCurrent: | 0.2C | 1 | 1 | StandardChargeCurrent: | 0.2C |
| HighLight: | lithiumpolymerbatterypack,highpowerbatterypack |
18650 lithium battery 11.1V35.2Ah library robot battery lithium battery pack
1. Technical Parameters
| Item | Rating | Note | ||
| Capacity | Typical | 35200mAh |
Discharge:7040mA , 7040mA |
|
| Min | 35200mAh | |||
| Energy | 390.72Wh | |||
|
Nominal Voltage
|
11.1V | |||
| AC Impedance Resistance | ≤200mΩ | |||
| Discharge Cut-off Voltage | 7.5V | |||
| Charge Voltage | 12.35V | |||
| Max. Charge Voltage | 12.40V | |||
| Charge Time | Approx 6.5h | 0.2C | ||
| Standard charge current | 7040mA | 0.2C | ||
| Max. Charge Current | 35200mA | 1.0C | ||
| Max. discharge current | ≤45℃ | 1.0C | ||
| Shipments voltage | ≥12.05V | |||
| Weight | Approx 1500g | |||
| Operating Temperature | Charge | 0~+60℃ | ||
| Discharge | -10~+60℃ | |||
HB lithium battery uses non-polluting materials and is produced with unique technology; it has fully passed UL safety certification, but as a lithium battery, like other types of cells, it has certain dangers when it is mechanically damaged. Therefore, the following precautions must be taken into consideration when handling and using HB lithium batteries:
Note the “plus positive ear” and “-negative ear “signs of the battery pack to ensure proper use.
Keep the battery pack clean and dry.
If the battery pack becomes extremely dirty, use a clean, dry cloth to wipe it.
Do not charge the battery pack for a long time.
The best performance and service life of the battery or battery pack can be obtained by charging and discharging at 15°C ~25°C.
Keep the original specification of the product for future reference.
Dispose of waste batteries or batteries in accordance with national environmental protection laws.
