25.2v 60ah Low Temperature Lithium Ion Battery High Safety No Pollution

Basic Information
Place of Origin: CHINA
Brand Name: HB
Certification: ROHS
Model Number: HB 21700 25.2V 60Ah 7S15P
Minimum Order Quantity: Contact sales to get
Price: Contact sales to get
Packaging Details: Contact sales to get
Delivery Time: Contact sales to get
Payment Terms: T/T
Supply Ability: Contact sales to get
Contact Now
Detail Information
Nominal Capacity: 60Ah Type: 21700CL
Size: 485*230*110mm Nominal Voltage: 25.2V
Cycle Life: ≥500 80% Weight: 10.5kg

Product Description

25.2V 60Ah Wide temperature battery AGV lithium battery customizat

1. Model



HB 21700 25.2V 60Ah 7S15P



2. Technical Parameters



Items Units property Remarks
Nominal capacity Ah 40 Ah 0.2C @25°C
Number of cores :: S*P 7 S10P
Product size mm L370*W230*H110 Weight: about 7kg
Voltage range V

17.5~29.4 V

14~29.4 V

-20~70℃

-40~-20℃

Nominal voltage V 25.2 V
Total energy kWh 1.008
Internal resistance <100



Continuous charging current

-20~-10℃ A 4 A
  -10~0℃ A 8 A
  0~60℃ A 20 A Adjustable
Continuous discharge current A 10 A Single (Open)
Cycle life Cycles ≥500 80% 0.2C charge/discharge



Storage temperature -40~70℃
Working relative humidity % 15~95
Air pressure KPA 86~106
BMS communication mode - RS232 Designed as required
Color of product - Army Green Color :#0215E21
Charge and discharge mode - Charge and discharge
Level of protection   IP67





3. Main Characteristics

- High low-temperature discharge performance

- Excellent low-temperature cycling performance

- Wide operating temperature range

- High safety and non-pollution



4. Application Area

Mainly used in military weapons, missile-borne vehicle equipment, cold zone rescue, aerospace, power communications, polar science, public safety, medical electronics, railways, ships, robots, etc.



5. Warning and Attention

HB lithium battery uses non-polluting materials and is produced with unique technology; it has fully passed UL safety certification, but as a lithium battery, like other types of cells, it has certain dangers when it is mechanically damaged. Therefore, the following precautions must be taken into consideration when handling and using HB lithium batteries:

1) It is forbidden to put the battery in water, and should be placed in a cool and dry environment during storage.

2) It is forbidden to use in the hot sunlight of moxibustion, otherwise it may cause battery overheating, fire or function failure.

3) It is prohibited to disassemble, open, chop or puncture the battery pack with metal.

4) It is forbidden to expose the battery or battery pack to heat or flame, to put the battery into the fire and to avoid storing it in direct sunlight.

5) It is forbidden to short-circuit batteries or batteries, and do not place multiple batteries in boxes or drawers at will to avoid shorting each other or by other metal objects.

6) It is prohibited to subject a battery or battery pack to mechanical shock.

7) In the event of leakage, do not contact the leaking liquid directly to the skin or eyes, if contact occurs, apply a large amount of water to flush the contact area.

8) Do not use non-special charging, which should be done in accordance with the manufacturer's instructions.

9) Note the "plus positive ear" and "-negative ear "signs of the battery pack to ensure proper use.

10) Keep the battery pack clean and dry.

If the battery pack becomes extremely dirty, use a clean, dry cloth to wipe it.

12) Do not charge the battery pack for a long time.

13) The best performance and service life of the battery or battery pack can be obtained by charging and discharging at 15°C ~25°C.

14) Keep the original specification of the product for future reference.

15) Dispose of waste batteries or batteries in accordance with national environmental protection laws.
