Custom Design Flexible Li Ion Battery 740mah 3.7v 500 Times Cycle Life

Basic Information
Place of Origin: CHINA
Brand Name: HB
Certification: ROHS
Model Number: 2826183-740mAh
Minimum Order Quantity: Contact sales to get
Price: Contact sales to get
Packaging Details: Contact sales to get
Delivery Time: Contact sales to get
Payment Terms: T/T
Supply Ability: Contact sales to get
Detail Information
Nominal Voltage: 3.7V Nominal Capacity: 740mAh
Warranty: 1 Year Cycle Life: 500 Times
Standard Discharge Current: 0.2C Standard Charge Current: 0.2C
High Light:

flexible lithium polymer battery

,

flexible rechargeable battery


Product Description

2826183 flexible battery 740mAh polymer lithium battery 3.7V custom battery




Item Rating Note

Capacity

Typical 740mAh

Discharge:148mA ,

148mA

Min 740mAh
Energy 2.81Wh

Nominal Voltage



3.80V

AC Impedance Resistance

≤150mΩ

Discharge Cut-off Voltage

3.0V

Charge Voltage

4.35V

Max. Charge Voltage

4.40V

Charge Time

Approx 6.5h 0.2C

Standard charge current

148mA 0.2C

Max. Charge Current

740mA 1.0C

Max. discharge current

≤45℃ 1.0C
Shipments voltage ≥4.05V
Weight Approx 17.0g

Operating Temperature

Charge 0~+60℃
Discharge -10~+60℃

Storage Temperature



less than 1

month

-10~+60℃

Recommended storage temperature: 20℃,at the transportation

less than 6

months

-10~+45℃





Features of flexible batteries


Traditional lithium batteries and supercapacitors are rigid. When they are bent or folded, it is easy to cause the electrode material and current collector to separate, affect the electrochemical performance, and even cause short circuits. Serious safety problems occur.

But the so-called flexible battery means that it can withstand bending and twisting and stretching even foldable batteries.


The battery can maintain stable electrochemical performance in a bent state and serves as an important energy storage device for wearable electronic devices.





3.Safety instructions



HB lithium battery uses non-polluting materials and is produced with unique technology; it has fully passed UL safety certification, but as a lithium battery, like other types of cells, it has certain dangers when it is mechanically damaged. Therefore, the following precautions must be taken into consideration when handling and using HB lithium batteries:

1) It is forbidden to expose the battery or battery pack to heat or flame, to put the battery into the fire and to avoid storing it in direct sunlight.

2) It is forbidden to short-circuit batteries or batteries, and do not place multiple batteries in boxes or drawers at will to avoid shorting each other or

3) It is forbidden to put the battery in water, and should be placed in a cool and dry environment during storage.

4) It is forbidden to use in the hot sunlight of moxibustion, otherwise it may cause battery overheating, fire or function failure.

5) It is prohibited to disassemble, open, chop or puncture the battery pack with metal.

by other metal objects.

6) It is prohibited to subject a battery or battery pack to mechanical shock.

7) In the event of leakage, do not contact the leaking liquid directly to the skin or eyes, if contact occurs, apply a large amount of water to flush the contact area.

8) Note the "plus positive ear" and "-negative ear "signs of the battery pack to ensure proper use.

9) Keep the battery pack clean and dry.

If the battery pack becomes extremely dirty, use a clean, dry cloth to wipe it.

10) Do not use non-special charging, which should be done in accordance with the manufacturer's instructions.12) Do not charge the battery pack for a long time.

11) The best performance and service life of the battery or battery pack can be obtained by charging and discharging at 15°C ~25°C.

12) Keep the original specification of the product for future reference.
